Specifications
Approved to: COLREG72,EN14744,IEC 60945,IACS
E10,USCG,ABS,M.E.D.,DNV,BV,RINA,LR,MCA,ATEX 2014/34/EU,IEC 60079-0/7/18,UK Ex
Operating temperature (°C): -25 to 55
Operating Voltage: 10-32VDC
Power draw (W): 1
Current consumption (mA @ 12VDC): 92
Current consumption (mA @ 24VDC): 56
Weight (Kg): 1,4
Light Color: Red
Visibility: 2nm
Mounting: Horizontal
Vessel size: 12-20M, 20-50M
Included In Package: 1 Navigation light, Installation guide
Materials: Black hard coatanodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
IP rating: IP68
Connection: Plug connector
Min. feed wire gauge: 0.5mm2 AWG22
