DHR70N SINGEL ALL ROUND RED 3NM
DHR70N SINGEL ALL ROUND RED 3NM
Item number:
SKU:200719
- Manufacturer number: 70170000
Couldn't load pickup availability
DHR70N lanterns are mandatory for seagoing vessels over 50 meters in length.
70170000
Specifications
Specifications
Applications: Sea-going vessels over 50m in length. Nato codification.
Materials: Matt black polyamide and polycarbonate, reinforced with fibreglass. Corrosion free, seawater resistant and non-magnetic. Polycarbonate Fresnel lens, shock resistant and interchangeable.
Wiring: 1,5 meter neoprene cable H07 RN-F 2x1,5.
PG13 Cable gland
Mounting: Base. Conversion kit for hoisting available.
Weight: Sector lights and 180° screened lights: 2.6 kg
All-round lights: 2.3 kg
Approval: MED 2014/90/EU
Visibility: 3NM
Protection class: IP56
All-round: Red
