Specifications
Approved to: COLREG72, EN14744, IEC 60945, IACS, E10
USCG, ABS, M.E.D., DNV, BV, RINA, LR, MCA, ATEX 2014/34/EU, IEC 60079-0/7/18, UK Ex
Operating temperature: -25°C to 55°C
Operating Voltage: 10-32VDC
Power draw (W): 1
Current consumption (mA @ 12VDC): 92
Current consumption (mA @ 24VDC): 56
Weight (Kg): 1,4
Light Color: Red
Visibility: 2NM
Mounting: Horizontal
Vessel size: 12-20m, 20-50m
Included In Package: 1 Navigation light, Installation guide.
Materials: Black hard coatanodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane.
IP rating: IP68
Connection: Plug connector
Min. feed wire gauge: 0.5mm2 AWG22
