Specifications
Approved to: COLREG72,EN14744,IEC 60945,IACS
E10,USCG,ABS,M.E.D.,DNV,LR
Operating temperature: -25°C to 55°
Operating Voltage: 10-32VDC
Power draw (W): 2,1
Current consumption (mA @ 12VDC): 150
Current consumption (mA @ 24VDC): 85
Weight (Kg): 0.45
Light Color: Green
Visibility: 2NM
Mounting: Horizontal
Vessel size: Under 12M, 12-20M, 20-50M
Included In Package: 1 Navigation light,precabled with 0,75 meter shielded marine grade cable, Installation guide
Materials: Black anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
IP rating: IP68
Connection: 0,7m cable
Min. feed wire gauge: 0.5mm2 AWG22
