NAV LIGHT 2NM, 360° RED, BLACK ANODIZED

NAV LIGHT 2NM, 360° RED, BLACK ANODIZED

Item number:

200856

  • Manufacturer number: 200-014G2-PRO
Logg inn for å se priser

Exc. VAT
  • Horizontally mounted on POM base (IP68)
  • Cable direction side
  • Incl. HDPE base plate
  • Quality cable glands - 2 sizes included:
  • 7-13mm (1/4"-1/2") cable diameter
  • 4.5-10mm (5/32"-3/8") cable diameter

200-014G2-PRO

Specifications

Approved to: COLREG72,EN14744,IEC 60945,IACS
E10,USCG,ABS,M.E.D.,DNV,LR

Operating temperature: -25°C to 55°C

Operating Voltage: 10-32VDC

Power draw (W): 2,1

Current consumption (mA @ 12VDC): 150

Current consumption (mA @ 24VDC): 85

Weight (Kg): 1

Light Color: Red

Intensity: >5.4cd

Visibility: 2nm

Mounting: Horizontal

Vessel size: Under 12M,12-20M,20-50M

Materials: Black hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy,  Polyurethane

IP rating:  IP68

Connection: Plug connector

Min. feed wire gauge: 0.5mm2 AWG22

Downloads:

Data sheet View full details
