NAV LIGHT 2NM, 360° WHITE, BLACK ANODIZED

NAV LIGHT 2NM, 360° WHITE, BLACK ANODIZED

Item number:

200855

  • Manufacturer number: 200-012G2-PRO
Logg inn for å se priser

Exc. VAT
  • Horizontally mounted on POM base (IP68)
  • Cable direction side
  • Incl. HDPE base plate
  • Quality cable glands - 2 sizes included:
  • 7-13mm (1/4"-1/2") cable diameter
  • 4.5-10mm (5/32"-3/8") cable diameter

200-012G2-PRO

Specifications

Approved to: COLREG72,EN14744,IEC 60945,IACS
E10,USCG,ABS,M.E.D.,DNV,LR

Operating temperature: -25°C to 55°C

Operating Voltage: 10-32VDC

Power draw (W): 2,6

Current consumption (mA @ 12VDC): 167

Current consumption (mA @ 24VDC): 110

Weight (Kg): 1 Kg

Light Color: White

Intensity: >5.4cd

Visibility: 2nm

Mounting: Horizontal

Vessel size: Under 12M,12-20M,20-50M

Included In Package: 1 Navigation light,Installation guide

Materials: Black hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy,  Polyurethane

IP rating:  IP68

Connection: Plug connector

Min. feed wire gauge: 0.5mm2 AWG22

Downloads:

Data sheet View full details
