Specifications
Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
Operating temperature (°C): -25 to 55
Operating Voltage: 10-32VDC
Power draw (W): 2,9
Current consumption (mA @ 12VDC): 210
Current consumption (mA @ 24VDC): 120
Weight (Kg): 1,15
Light Color: Red
Intensity: >15cd
Visibility: 3NM
Mounting: Horizontal
Vessel size: Over 50m
Included In Package: 1 Navigation light, Installation guide.
Materials: Black anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane.
IP rating: 68
Connection: Plug connector
Min. feed wire gauge: 0.5mm2 AWG22
