Specifications
Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
Operating temperature: -60°C to 55°C
Operating Voltage: 20-32VDC
Power draw (W): 2,6
Current consumption (mA @ 12VDC): 183
Current consumption (mA @ 24VDC): 110
Weight (Kg): 1,2
Light Color: Green
Intensity: >15cd
Visibility: 3NM
Mounting: Horizontal
Vessel size: Over 50M
Included In Package: 1 Navigation light, 2 Mounting
screws (M6 * 8 mm), Installation guide.
Materials: Black hard coat anodized aluminum 50μ, PMMA lens, A4 stainless steel screws, Epoxy,
Polyurethane.
IP rating: IP68
Connection: Plug connector
Min. feed wire gauge: 1.5mm2 AWG18
