Specifications
Approved to: COLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR
Operating temperature: -25°C to 55°C
Operating Voltage : 10-32VDC
Power draw (W): 2
Current consumption (mA @ 12VDC): 137
Current consumption (mA @ 24VDC): 80
Weight (Kg): 0.48
Light Color: White
Visibility: 3NM
Mounting: Horizontal
Vessel size: 12-20m
Included In Package: 1 Navigation light, precabled with 0.75 meter shielded marine grade cable, installation guide.
Materials: Silver anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane.
IP rating: IP68
Connection: 0.75m cable
Min. feed wire gauge: 0.5mm2 AWG22
